VLAN Configuration Command Set
Assigning Port VLAN IDs (PVIDs) and Ingress Filtering
7-14 Matrix DFE-Platinum and Diamond Series Configuration Guide
7.3.3.2 set port vlan
Use this command to configure the PVID (port VLAN identifier) for one or more ports. The PVID
is used to classify untagged frames as they ingress into a given port. If the specified VLAN has not
already been created, this command will create it. It will prompt the user to add the VLAN to the
port’s egress list as untagged, and remove the default VLAN from the port’s egress list.
set port vlan port-string pvid [modify-egress | no-modify-egress]
Syntax Description
Command Defaults
If not specified, the egress list will be modified.
Command Type
Switch command.
Command Mode
Read-Write.
NOTE: For information on how to configure protocol-based policy classification to a
VLAN, including how to configure a VLAN policy to override PVID, refer to Chapter 8.
port-string Specifies the port(s) for which to configure a VLAN
identifier. For a detailed description of possible port-string
values, refer to Section 4.1.1.
pvid Specifies the VLAN ID of the VLAN to which port(s) will
be added.
modify-egress |
no-modify-egress
(Optional) Adds port(s) to VLAN's untagged egress list and
removes them from other untagged egress lists, or does not
prompt for or make egress list changes
