Spanning Tree Configuration Command Set
Configuring Spanning Tree Bridge Parameters
6-36 Matrix DFE-Platinum and Diamond Series Configuration Guide
6.2.1.24 show spantree priority
Use this command to display the Spanning Tree bridge priority.
show spantree priority [sid]
Syntax Description
Command Defaults
If sid is not specified, priority will be shown for Spanning Tree 0.
Command Type
Switch command.
Command Mode
Read-Only.
Example
This example shows how to show the bridge priority for Spanning Tree 0
sid (Optional) Displays the priority for a specific
Spanning Tree. Valid values are 0 - 4094. If not
specified, SID 0 is assumed.
Matrix(rw)->show spantree priority
Bridge Priority is set to 4096 on sid 0
