VLAN Configuration Command Set
Enabling/Disabling GVRP
7-48 Matrix DFE-Platinum and Diamond Series Configuration Guide
7.3.6.6 clear garp timer
Use this command to reset GARP timers back to default values.
clear garp timer {[join] [leave] [leaveall]} port-string
Syntax Description
Command Defaults
At least one optional parameter must be entered.
Command Type
Switch command.
Command Mode
Read-Write.
Example
This example shows how to reset the GARP leave timer to 60 centiseconds on Fast Ethernet port 5
in module 2:
join (Optional) Resets the join timer to 20 centiseconds.
leave (Optional) Resets the leave timer to 60 centiseconds.
leaveall (Optional) Resets the leaveall timer to 1000 centiseconds.
port-string Specifies the port(s) on which to reset GARP timer(s). For a
detailed description of possible port-string values, refer to
Section 4.1.1.
Matrix(rw)->clear garp timer leave fe.2.5
