Discovery Protocols Command Set
Link Layer Discovery Protocol and LLDP-MED
Matrix DFE-Platinum and Diamond Series Configuration Guide 3-51
mac-phy MAC-PHY Configuration/Status IEEE 802.3 Extensions
TLV. Value sent includes the operational MAU type,
duplex, and speed of the port.
poe Power via MDI IEEE 802.3 Extensions TLV. Values sent
include whether pair selection can be controlled on port,
and the power class supplied by the port. Only valid for
PoE-enabled ports.
link-aggr Link Aggregation IEEE 802.3 Extensions TLV. Values
sent indicate whether the link associated with this port can
be aggregated, whether it is currently aggregated, and if
aggregated, the aggregated port identifier.
max-frame Maximum Frame Size IEEE 802.3 Extensions TLV.
Value sent indicates maximum frame size of the port’s
MAC and PHY.
med-cap LLDP-MED Capabilities TLV.Value sent indicates the
capabilities (whether the device supports location
information, network policy, extended power via MDI)
and Device Type (network connectivity device) of the
sending device.
med-pol LLDP-MED Network Policy TLV. Values sent include
application name, VLAN type (tagged or untagged),
VLAN ID, and both Layer 2 and Layer 3 priorities
associated with application, for all applications enabled on
the port. See the set lldp port network-policy command for
more information.
med-loc LLDP-MED Location Identification TLV. Value sent is
the ECS ELIN value configured on the port. See the set
lldp port location-info command for more information.
med-poe LLDP-MED Extended Power via MDI TLV. Values sent
include the Power Limit (total power the port is capable of
sourcing over a maximum length cable) and the power
priority configured on the port. Only valid for
PoE-enabled ports.
port-string Specifies the port or range of ports to be affected.
