Page #361 background image
Configuring LACP
Configuring Link Aggregation
Matrix DFE-Platinum and Diamond Series Configuration Guide 4-101
Table 4-9 show lacp Output Details
Output What It Displays...
Aggregator LAG port designation. Each Matrix Series module provides
48 virtual link aggregator ports, which are designated in the
CLI as lag.0.1 through lag.0.48. Once underlying physical
ports (i.e.; fe.x.x, ge.x.x) are associated with an aggregator
port, the resulting Link Aggregation Group (LAG) is
represented with a lag.x.x port designation.
Actor Local device participating in LACP negotiation.
Partner Remote device participating in LACP negotiation.
System Identifier MAC addresses for actor and partner.
System Priority System priority value which determines aggregation
precedence. Only one LACP system priority can be set on a
Matrix Series device, using either the set lacp asyspri
command (Section 4.5.4.4), or the set port lacp command
(Section 4.5.4.13)
.
Admin Key Port’s administratively assigned key.
Oper Key Port’s operational key, derived from the admin key. Only
underlying physical ports with oper keys matching the
aggregator’s will be allowed to aggregate.
Attached Ports Underlying physical ports associated with this aggregator.
