Spanning Tree Configuration Command Set
Configuring Spanning Tree Bridge Parameters
6-10 Matrix DFE-Platinum and Diamond Series Configuration Guide
Examples
This example shows how to display the device’s Spanning Tree configuration:
Table 6-1 shows a detailed explanation of command output.
Matrix(rw)->show spantree stats
Spanning tree status - enabled
Spanning tree instance - 0
Designated Root MacAddr - 00-e0-63-9d-c1-c8
Designated Root Priority - 0
Designated Root Cost - 10000
Designated Root Port - lag.0.1
Root Max Age - 20 sec
Root Hello Time - 2 sec
Root Forward Delay - 15 sec
Bridge ID MAC Address - 00-01-f4-da-5e-3d
Bridge ID Priority - 32768
Bridge Max Age - 20 sec
Bridge Hello Time - 2 sec
Bridge Forward Delay - 15 sec
Topology Change Count - 7
Time Since Top Change - 00 days 03:19:15
Max Hops - 20
Table 6-1 show spantree Output Details
Output What It Displays...
Spanning tree instance Spanning Tree ID.
Spanning tree status Whether Spanning Tree is enabled or disabled.
Designated Root MacAddr MAC address of the designated Spanning Tree root bridge.
Designated Root Port Port through which the root bridge can be reached.
Designated Root Priority Priority of the designated root bridge.
Designated Root Cost Total path cost to reach the root.
Root Max Age Amount of time (in seconds) a BPDU packet should be
considered valid.
Root Hello Time Interval (in seconds) at which the root device sends BPDU
(Bridge Protocol Data Unit) packets.
