Discovery Protocols Command Set
Link Layer Discovery Protocol and LLDP-MED
3-34 Matrix DFE-Platinum and Diamond Series Configuration Guide
Table 3-4 describes the information displayed by the show lldp port local-info command.
Operational Speed/Duplex/Type : 100 full tx
Max Frame Size (bytes) : 1522
Vlan Id : 1
LAG Supported/Enabled/Id : no/no/0
Protocol Id : Spanning Tree v-3 (IEEE802.1s)
LACP v-1
GVRP
Network Policy
(app/tag/vlanId/cos/dscp) : voice/tagged/10/3/5
voice signaling/tagged/10/3/5
guest voice/tagged/10/3/5
guest voice signaling/tagged/10/3/5
softphone voice/tagged/10/3/5
video conferencing/tagged/10/3/5
streaming video/tagged/10/3/5
video signaling/tagged/10/3/5
ECS ELIN : 1234567890123456789012345
PoE Device : PSE device
PoE Power Source : primary
PoE MDI Supported/Enabled : yes/yes
PoE Pair Controllable/Used : false/spare
PoE Power Class : 2
PoE Power Limit (mW) : 15400
PoE Power Priority : high
Table 3-4 show lldp port local-info Output Details
Output Field What it Displays ...
Local Port Identifies the port for which local system information is displayed.
Local Port Id Mandatory basic LLDP TLV that identifies the port transmitting
the LLDPDU. Value is ifName object defined in RFC 2863.
Port Desc Optional basic LLDP TLV. Value is ifDescr object defined in RFC
2863.
Mgmt Addr Optional basic LLDP TLV. IPv4 address of host interface.
