Discovery Protocols Command Set
Link Layer Discovery Protocol and LLDP-MED
Matrix DFE-Platinum and Diamond Series Configuration Guide 3-35
Chassis ID Mandatory basic LLDP TLV that identifies the chassis
transmitting the LLDPDU. Value is MAC address of chassis.
Sys Name Optional basic LLDP TLV. Value is the administratively assigned
name for the system.
Sys Desc Optional basic LLDP TLV. Value is sysDescr object defined in
RFC 3418.
Sys Cap Supported/Enabled Optional basic LLDP TLV. System capabilities, value can be
bridge and/or router.
Auto-Neg
Supported/Enabled
IEEE 802.3 Extensions MAC-PHY Configuration/Status TLV.
Auto-negotiation supported and enabled settings should be the
same on the two systems attached to the same link.
Auto-Neg Advertised IEEE 802.3 Extensions MAC-PHY Configuration/Status TLV.
Lists the configured advertised values on the port.
Operational
Speed/Duplex/Type
IEEE 802.3 Extensions MAC-PHY Configuration/Status TLV.
Lists the operational MAU type, duplex, and speed of the port. If
the received TLV indicates that auto-negotiation is supported but
not enabled, these values will be used by the port.
Max Frame Size (bytes) IEEE 802.3 Extensions Maximum Frame Size TLV. Value
indicates maximum frame size capability of the device’s MAC and
PHY. In normal mode, max frame size is 1522 bytes. In jumbo
mode, max frame size is 10239 bytes.
Vlan Id IEEE 802.1 Extensions Port VLAN ID TLV. Value is port VLAN
ID (pvid).
LAG Supported/Enabled/Id IEEE 802.3 Extensions Link Aggregation TLV. Values indicate
whether the link associated with this port can be aggregated,
whether it is currently aggregated, and if aggregated, the
aggregated port identifier.
Protocol Id IEEE 802.1 Extensions Protocol Identity TLV. Values can include
Spanning tree, LACP, and GARP protocols and versions. Only
those protocols enabled on the port are displayed.
Table 3-4 show lldp port local-info Output Details
Output Field What it Displays ...
