CHANNEL-GROUP
channel-group <0-30> timeslots <1-31> speed [56K|64K]
DESCRIPTION
This command is entered in the Controller Configuration Mode. This command is
used to create channel-groups that vary from 0-30 and set timeslots that vary from
1-31.
PARAMETERS
DEFAULT VALUE
Default speed is 64 Kbps.
EXAMPLE
1. Variations of the channel-group to associate different timeslots with the
serial interface are shown:
To associate all the timeslots with the controller:
ALU(config-controller T1)#channel-group 0 timeslots 1-24
To associate contiguous timeslots with the controller:
ALU(config-controller T1)#channel-group 0 timeslots 1-10
ALU(config-controller T1)#channel-group 0 timeslots 1,2,3
To associate non-contiguous timeslots with the controller:
ALU(config-controller T1)#channel-group 0 timeslots 1,4,20
Parameter Description
0-30 The number of channels that can be
configured on the controller.
1-31 Range of the timeslots that can be associated
with the controller. Could be specified as
contiguous: 1,2,3 or 1-3 or could be specified
as non-contiguous: 1,4,7.
56K|64K The speed of the underlying DS0s: 56 Kbps/64
Kbps.
