SHOW IP RIP PEERS
show ip rip peers [vrf <vrf-name>]
DESCRIPTION
This command is entered in the Super User Mode or Configuration Mode. This
command displays the RIP peer table details.
PARAMETERS
PLATFORMS SUPPORTED
OmniAccess 5740 USG
EXAMPLE
ALU# show ip rip peers
RIP Peer Table
--------------
Peer Address Interface LastUpd(sec) Rcv Ver Bad Pkts BadRoutes
1.1.1.1 GigabitEthernet3/0 865 2 0 0
10.91.2.5 GigabitEthernet3/1 25 2 0 0
ALU#
RELEASE HISTORY
Release 2.3: Parameter [vrf <vrf-name>] was added.
Parameter Description
vrf-name
Name of the VRF.
Peer Address IP address of the peer.
Interface
The interface-type.
Last Update
(secs)
The time of the last update (in secs).
Rcv Ver The Receive Version.
Bad Pkts The number of bad packets received.
Bad Routes The number of bad routes received.
