Frame Relay
Left running head:
Chapter name (automatic)
280
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Command Reference Guide
Alcatel-Lucent
FRAME-RELAY KEEPALIVE
frame-relay keepalive <0-32767>
DESCRIPTION
This command is entered in the Interface Configuration Mode. This command is
used to configure the LMI Keepalive interval. The LMI keepalive value should
typically be equal to the corresponding interval at the switch.
PARAMETERS
DEFAULT VALUE
The default LMI keepalive value is 10.
EXAMPLE
The following example sets the LMI keepalive interval to 12.
ALU(config-if Serial0/0:0)# frame-relay keepalive 12
FRAME-RELAY LMI-TYPE
frame-relay lmi-type {ansi|q933a}
DESCRIPTION
This command is entered in the Interface Configuration Mode. This command
sets the LMI type to either ANSI or Q933A.
PARAMETERS
DEFAULT VALUE
The default LMI type is auto-sense. LMI Autosense is activated by default as the
system acts as a DTE. The LMI autosense will be activated when the physical
interface is up and LMI type is not configured on that interface.
EXAMPLE
The following example sets the LMI to ansi standard.
ALU(config-if serial0/0:0)# frame-relay lmi-type ansi
Parameter Description
0-32767 LMI keep alive interval in the range 0 to 32767.
Parameter Description
ansi American National Standards Institute T1.617
Annex D.
q933a ITU-T Q.933 Annex A.
