SHOW IP ROUTE
show ip route [{network-number|ip-address/prefix length}
[longer-prefixes]|ospf [<1-65535>]|connected|bgp|rip
|summary|supernets-only|vrf <vrf-name>]
DESCRIPTION
This command is entered in the Super User Mode or Configuration Mode. This
command displays the current state of a routing protocol. You can filter show IP
route output to view specific protocol routes.
PARAMETERS
EXAMPLE
Example 1
ALU# show ip route
Codes: R - RIP, O - OSPF, C - connected
S - static, M - mcstatic, B - BGP
IA - OSPF inter area route, E1 - OSPF external type 1 route,
E2 - OSPF external type 2 route, N1 - OSPF NSSA external type 1 route,
N2 - OSPF NSSA external type 2 route
* - candidate default route
Gateway of last resort is not set
5.0.0.0/24 is subnetted, 3 subnets
C 5.5.0.0 [0/0] is directly connected, Serial0/0:0
C 5.5.1.0 [0/0] is directly connected, Serial0/0:1
C 5.5.2.0 [0/0] is directly connected, Serial0/0:2
6.0.0.0 is variably subnetted, 2 subnets, 2 masks
S 6.6.6.0/24 [1/0] is directly connected, Serial0/0:2
O 6.6.6.6/32 [110/10][1] via 5.5.0.1, Serial0/0:0
via 5.5.1.1, Serial0/0:1
via 5.5.2.1, Serial0/0:2
S 7.0.0.0/8 [1/0] is directly connected, Serial0/0:0
is directly connected, Serial0/0:1
10.0.0.0/24 is subnetted, 1 subnet
C 10.91.2.0 [0/0] is directly connected, GigabitEthernet3/0
Field Description
{network-number|ip-
address/prefix length}
Displays the routing information for the given
network number or IP address and prefix length.
longer-prefixes Specifies that only routes matching the IP address
and mask pair should be displayed.
[ospf [<1-65535>]
|connected|bgp|rip
|summary|supernets-
only]
Displays the output for a specific routing protocols.
vrf <vrf-name> Name of the VRF.
