Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Command Reference Guide
2. In the above example, the channel-group command is shown only with a
value of ‘0’. The following example uses value in the range of 0-23:
To configure multiple channel groups with absolute values of timeslots:
ALU(config-controller T1)#channel-group 0 timeslots 1
ALU(config-controller T1)#channel-group 1 timeslots 2
To configure multiple channel groups with contiguous values of timeslots:
ALU(config-controller T1)#channel-group 3 timeslots 10-13
To configure multiple channel groups with non-contiguous values of timeslots:
ALU(config-controller T1)#channel-group 2 timeslots 3,6,9
CLOCKSOURCE
clocksource {internal|line}
DESCRIPTION
This command is entered in the Controller Configuration Mode to set clocksource
for T1 interface. The keyword "clocksource" is used to transmit clock signals.
PARAMETERS
DEFAULT VALUE
Default clocksource is internal.
EXAMPLE
The following example configures the T1 clocksource for line:
ALU(config-controller T1)# clocksource line
Parameter Description
internal
The controller synchronizes itself to the internal
(system) clock.
line
The controller recovers external clock from the
line and provides the recovered clock to the
internal (system) clock generator.
