Border Gateway Protocol
Left running head:
Chapter name (automatic)
546
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Command Reference Guide
Alcatel-Lucent
SHOW IP BGP SUMMARY
show ip bgp summary
DESCRIPTION
This command is entered in the Super User Mode or Configuration Mode. This
command verifies whether peering is established with the router’s neighbors and
displays the basic statistics for messages and prefixes.
PARAMETERS
None.
EXAMPLE
ALU# show ip bgp summary
BGP router identifier 111.111.111.111, local AS number 200
7 Prefix entries using 416 bytes of memory
7 Path entries for prefixes using 392 bytes of memory
Dampening enabled. 0 History paths. 2 Dampened paths
3 Path attribute entries using 672 bytes of memory
2 Aspath entries using 614 bytes of memory
2 Community entries using 44 bytes of memory
Neighbor V AS MsgRcvd MsgSent InQ OutQ Up/Down State/PfxRcd
1.1.1.2 4 100 342 333 0 0 00:12:46 5
111.111.111.112 4 300 323 331 0 0 00:17:39 2
ALU#
Field Description
BGP router
identifier
In order of precedence and availability, router identifier
specified by the BGP router-id command, loopback
address, or lowest IP address.
local AS Local AS number.
Neighbor IP address of a neighbor.
V BGP version number spoken to that neighbor.
AS Neighbor AS number.
MsgRcvd BGP messages received from that neighbor.
MsgSent BGP messages sent to that neighbor.
InQ Number of messages from that neighbor waiting to be
processed.
OutQ Number of messages waiting to be sent to that neighbor.
