Quality of Service
Left running head:
Chapter name (automatic)
906
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Command Reference Guide
Alcatel-Lucent
SET
set {ecn-ce|fr-becn|fr-de|fr-fecn|ip-dscp {<0-63>|<dscp-
mnemonics>}|ip-precedence {<0-7>|<precedence-mnemonics>}|tos
{<0-15>|<tos-mnemonics>}|vlan 1p}
DESCRIPTION
This command is entered in the Class Mode. This command is used to set the
- IP Precedence/IP DSCP/ToS flags on the matched packet
- FECN, BECN, DE bits marking on the FR interface and
- 802.1p marking on the VLAN interface.
PARAMETERS
DSCP MNEMONICS
Parameter Description
0-63 DSCP value in the range 0 - 63.
dscp-mnemonics IP-DSCP mnemonics. See table below.
0-7 DSCP value in the range 0 - 63.
precedence-mnemonics IP-precedence mnemonics. See table
below.
0-15 DSCP value in the range 0 - 63.
tos-mnemonics ToS mnemonics. See table below.
DSCP Mnemonics Values
default 0
cs1 8
cs2 16
cs3 24
cs4 32
cs5 40
cs6 48
cs7 56
ef 46
af11 10
af12 12
