Virtual Routing and Forwarding
Left running head:
Chapter name (automatic)
662
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Command Reference Guide
Alcatel-Lucent
SHOW IP ROUTE
show ip route [vrf <vrf-name>] [{network-number|ip-ddress/
prefix length} [longer-prefixes]|ospf [<1-65535>]
|connected|bgp|rip|summary|supernets-only]
DESCRIPTION
This command is entered in the Super User Mode or Configuration Mode. This
command displays the IP routing table for the default VRF.
PARAMETERS
PLATFORMS SUPPORTED
OmniAccess 5740 USG
EXAMPLE
ALU(config)# show ip route vrf ALU-vrf
Codes: R - RIP, O - OSPF, C - connected
S - static, M - mcstatic, B - BGP, A - ASE
IA - OSPF inter area route, E1 - OSPF external type 1 route,
E2 - OSPF external type 2 route, N1 - OSPF NSSA external type 1 route,
N2 - OSPF NSSA external type 2 route
* - candidate default route
Gateway of last resort is not set
1.0.0.0 is variably subnetted, 2 subnets, 2 masks
B 1.0.0.0/8 [20/0] via 4.4.4.1, GigabitEthernet3/0
O 1.1.1.0/24 [110/110][1] via 4.4.4.1, GigabitEthernet3/0
4.0.0.0 is variably subnetted, 2 subnets, 2 masks
B 4.0.0.0/8 [20/0] via 4.4.4.1, GigabitEthernet3/0
C 4.4.4.0/24 [0/0] is directly connected, GigabitEthernet3/0
B 5.0.0.0/8 [20/0] via 4.4.4.1, GigabitEthernet3/0
ALU(config)#
RELEASE HISTORY
Release 2.3: command was introduced.
Field Description
vrf-name The name of the VRF for which the routing
information is to be viewed.
{network-number|ip-
ddress/prefix length}
Displays the routing information for the given network
number or IP address and prefix length.
longer-prefixes Specifies that only routes matching the IP address
and mask pair should be displayed.
ospf [<1-65535>]
|connected|bgp|rip|su
mmary|supernets-only]
Displays the output for a specific routing protocols.
