T1E1 Line Card
Left running head:
Chapter name (automatic)
250
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Command Reference Guide
Alcatel-Lucent
CHANNEL-GROUP
channel-group <0-23> timeslots <1-24> speed [56K|64K]
DESCRIPTION
This command is entered in the Controller Configuration Mode to create channel-
groups that vary from 0-23 and set timeslots that vary from 1-24. Creating the
channel group and defining the time slot will enable the interface on that
controller.
PARAMETERS
DEFAULT VALUE
Default speed is 64kbps.
EXAMPLE
1. Variations of the channel-group to associate different timeslots with the
serial interface are shown:
To associate all the timeslots with the controller:
ALU(config-controller T1)#channel-group 0 timeslots 1-24
To associate contiguous timeslots with the controller:
ALU(config-controller T1)#channel-group 0 timeslots 1-10
ALU(config-controller T1)#channel-group 0 timeslots 1,2,3
To associate non-contiguous timeslots with the controller:
ALU(config-controller T1)#channel-group 0 timeslots 1,4,20
Parameter Description
0-23 The number of channels that can be
configured on the controller.
1-24 Range of the timeslots that can be
associated with the controller. Could be
specified as contiguous: 1,2,3 or 1-3 or
could be specified as non-contiguous:
1,4,7.
56K|64K The speed of the underlying DS0s: 56
kbps or 64 kbps. Default speed is 64
kbps.
