match-lists (rulesets)
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
407
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Command Reference Guide
This command is entered in the Match-list Configuration Mode. The following
command is used to configure rules for ICMP in a match-list:
[<1-1024>] icmp {any|host <source ip-address>|interface
<name>|list <name>|prefix <source ip-address/prefix length>}
{any|host <destination ip-address>|interface <name>|list
<name>|prefix <destination ip-address/prefix length>} [dscp
{<0-63>|<dscp-mnemonics>|fragment|icmp-type <0-255> [icmp-
subtype <0-255>]|ip-precedence {<0-7>|<precedence-
mnemonics>}|length {<1-1500>|{eq|ge|gt|le|lt|range <1-
1500>}}|tos {<0-15>|<tos-mnemonics>}]
This command is entered in the Match-list Configuration Mode. The following
command is used to configure rules using the protocol numbers:
[<1-1024>] protocol <1-65535> {any|host <source ip-address>
|interface <name> |list <name>|prefix <source ip-address/
prefix length>} {any|host <destination ip-address>|interface
<name>|list <name>|prefix <destination ip-address/prefix
length>} [dscp {<0-63>|<dscp-mnemonics>|fragment|ip-
precedence {<0-7>|<precedence-mnemonics>} |length {<1-1500>
|{eq|ge|gt|le|lt|range <1-1500>}} |tos {<0-15>|<tos-
mnemonics>}|type {ftp|normal|rpc|rtcp|rtp|
sip|tftp}]
PARAMETERS
Parameter Description
1-1024 Line/Rule numbers to specify the rule priority.
ip|tcp|udp|igmp|icmp|... IP Protocol type, such as UDP, TCP, ICMP, etc.
any Indicates a wildcard match. Source being
anything.
host <source ip-address> Source address.
interface <interface-
name>
Name of the interface.
list <name> Name of the list.
prefix <source ip-
address/prefix length>
Source address with prefix length.
host <destination ip-
address>
Destination address.
prefix <destination ip-
address/prefix length>
Destination address with prefix length.
dscp <0-63> <dscp-
mnemonics>
Denotes the DSCP value.
