OmniAccess 5740 Unified Services Gateway CLI Command Reference Guide
To Configure a Rule Inside an IP Policy:
[<1-65535>] match [{all|any}] <match-list name>...[not
<match-list name>] {for-us|interface <interface-name> [next-
hop <ip-address>]|next-hop <ip-address>}
This command is entered in the PBR Configuration Mode. This command is used
to configure rules (set priority for the rule, associate match-lists and action) for an
IP policy.
Example
ALU(config-ip-policy-pbr1)# 10 match m1 m2 not m3 interface
GigabitEthernet 3/0 next hop 1.2.2.1
ALU(config-ip-policy-pbr1)# 20 match m1 m2 next hop 1.2.2.2
Parameter Description
1-65535 Denotes the routing policy rule number.
The range for the IP policy rule.
match [{all|any}] <match-list
name>...
match all - In this type of match, the
relevant action is performed only when
all the match-list criteria is satisfied.
match any - In this type of match, the
relevant action is performed even if any
one of the match-list criterion is satisfied.
not <match-list name>] Specifies match-list with not option.
for-us This keyword redirects the packet to the
management plane of the OmniAccess
5740 USG.
interface <interface-name>
[next-hop <ip-address>]
Specifies the egress path of the packet.
If the interface and next-hop are
specified together, then the packet shall
be forwarded to the specified next-hop
on the specified interface.
next-hop <ip-address> Specifies the egress path of the packet.
