Register 47: Synchronous Serial Interface Peripheral Present (PPSSI), offset
0x31C
The PPSSI register provides software information regarding the SSI modules.
Important: This register should be used to determine which SSI modules are implemented on this
microcontroller. However, to support legacy software, the DC2 register is available. A
read of the DC2 register correctly identifies if a legacy SSI module is present. Software
must use this register to determine if a module that is not supported by the DC2 register
is present.
Synchronous Serial Interface Peripheral Present (PPSSI)
Base 0x400F.E000
Offset 0x31C
Type RO, reset 0x0000.000F
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
P0P1P2P3reserved
ROROROROROROROROROROROROROROROROType
1111000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:4
SSI Module 3 Present
DescriptionValue
SSI module 3 is not present.0
SSI module 3 is present.1
0x1ROP33
SSI Module 2 Present
DescriptionValue
SSI module 2 is not present.0
SSI module 2 is present.1
0x1ROP22
SSI Module 1 Present
DescriptionValue
SSI module 1 is not present.0
SSI module 1 is present.1
0x1ROP11
331June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
