Table 5-11. System Control Register Map (continued)
See
page
DescriptionResetTypeNameOffset
263Interrupt Mask Control0x0000.0000RWIMC0x054
265Masked Interrupt Status and Clear0x0000.0000RW1CMISC0x058
267Reset Cause0x0000.0002RWRESC0x05C
270Power-Temperature Cause0x0000.0000RW1CPWRTC0x060
271NMI Cause Register0x0000.0000RWNMIC0x064
273Main Oscillator Control0x0000.000CRWMOSCCTL0x07C
275Run and Sleep Mode Configuration Register0x0000.0000RWRSCLKCFG0x0B0
277
Memory Timing Parameter Register 0 for Main Flash and
EEPROM
0x0030.0030RWMEMTIM00x0C0
280Alternate Clock Configuration0x0000.0000RWALTCLKCFG0x138
281Deep Sleep Clock Configuration Register0x0000.0000RWDSCLKCFG0x144
284Divisor and Source Clock Configuration0x0000.0000RWDIVSCLK0x148
286System Properties0x0003.1F31ROSYSPROP0x14C
289Precision Internal Oscillator Calibration0x0000.0000RWPIOSCCAL0x150
291Precision Internal Oscillator Statistics0x0040.0040ROPIOSCSTAT0x154
292PLL Frequency 00x0000.0000RWPLLFREQ00x160
293PLL Frequency 10x0000.0000RWPLLFREQ10x164
294PLL Status0x0000.0000ROPLLSTAT0x168
295Sleep Power Configuration0x0000.0000RWSLPPWRCFG0x188
297Deep-Sleep Power Configuration0x0000.0000RWDSLPPWRCFG0x18C
299Non-Volatile Memory Information0x0000.0001RONVMSTAT0x1A0
300LDO Sleep Power Control0x0000.0018RWLDOSPCTL0x1B4
302LDO Sleep Power Calibration0x0000.1818ROLDOSPCAL0x1B8
303LDO Deep-Sleep Power Control0x0000.0012RWLDODPCTL0x1BC
305LDO Deep-Sleep Power Calibration0x0000.1212ROLDODPCAL0x1C0
306Sleep / Deep-Sleep Power Mode Status0x0000.0000ROSDPMST0x1CC
309Reset Behavior Control Register0xFFFF.FFFFRWRESBEHAVCTL0x1D8
311Hardware System Service Request0x0000.0000RWHSSR0x1F4
312USB Power Domain Status0x0000.003FROUSBPDS0x280
313USB Memory Power Control0x0000.0003RWUSBMPC0x284
314Ethernet MAC Power Domain Status0x0000.003FROEMACPDS0x288
315Ethernet MAC Memory Power Control0x0000.0003RWEMACMPC0x28C
June 18, 2014248
Texas Instruments-Production Data
System Control
