Register 126: 16/32-Bit General-Purpose Timer Deep-Sleep Mode Clock Gating
Control (DCGCTIMER), offset 0x804
The DCGCGPT32 register provides software the capability to enable and disable 16/32-bit timer
modules in deep-sleep mode. When enabled, a module is provided a clock. When disabled, the
clock is disabled to save power.
Important: This register should be used to control the clocking for the timer modules.
16/32-Bit General-Purpose Timer Deep-Sleep Mode Clock Gating Control (DCGCTIMER)
Base 0x400F.E000
Offset 0x804
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
D0D1D2D3D4D5D6D7reserved
RWRWRWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:8
16/32-Bit General-Purpose Timer 7 Deep-Sleep Mode Clock Gating
Control
DescriptionValue
16/32-bit general-purpose timer module 7 is disabled in
deep-sleep mode.
0
Enable and provide a clock to 16/32-bit general-purpose timer
module 7 in deep-sleep mode.
1
0RWD77
16/32-Bit General-Purpose Timer 6 Deep-Sleep Mode Clock Gating
Control
DescriptionValue
16/32-bit general-purpose timer module 6 is disabled in
deep-sleep mode.
0
Enable and provide a clock to 16/32-bit general-purpose timer
module 6 in deep-sleep mode.
1
0RWD66
16/32-Bit General-Purpose Timer 5 Deep-Sleep Mode Clock Gating
Control
DescriptionValue
16/32-bit general-purpose timer module 5 is disabled in
deep-sleep mode.
0
Enable and provide a clock to 16/32-bit general-purpose timer
module 5 in deep-sleep mode.
1
0RWD55
June 18, 2014428
Texas Instruments-Production Data
System Control
