Register 14: ADC Control (ADCCTL), offset 0x038
This register configures the voltage reference. The voltage references for the conversion can be
VREFA+ and GNDA or VDDA and GNDA. Note that values set in this register apply to all ADC modules,
it is not possible to set one module to use internal references and another to use external references.
ADC Control (ADCCTL)
ADC0 base: 0x4003.8000
ADC1 base: 0x4003.9000
Offset 0x038
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
VREFreserved
RWROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.000ROreserved31:1
Voltage Reference Select
DescriptionValue
VDDA and GNDA are the voltage references for all ADC modules.0x0
The external VREFA+ and GNDA are the voltage references for
all ADC modules.
0x1
0x0RWVREF0
June 18, 20141108
Texas Instruments-Production Data
Analog-to-Digital Converter (ADC)
