Table 10-7. GPIO Register Map
See
page
DescriptionResetTypeNameOffset
759GPIO Data0x0000.0000RWGPIODATA0x000
760GPIO Direction0x0000.0000RWGPIODIR0x400
761GPIO Interrupt Sense0x0000.0000RWGPIOIS0x404
762GPIO Interrupt Both Edges0x0000.0000RWGPIOIBE0x408
763GPIO Interrupt Event0x0000.0000RWGPIOIEV0x40C
764GPIO Interrupt Mask0x0000.0000RWGPIOIM0x410
765GPIO Raw Interrupt Status0x0000.0000ROGPIORIS0x414
767GPIO Masked Interrupt Status0x0000.0000ROGPIOMIS0x418
769GPIO Interrupt Clear0x0000.0000W1CGPIOICR0x41C
770GPIO Alternate Function Select-RWGPIOAFSEL0x420
772GPIO 2-mA Drive Select0x0000.00FFRWGPIODR2R0x500
773GPIO 4-mA Drive Select0x0000.0000RWGPIODR4R0x504
774GPIO 8-mA Drive Select0x0000.0000RWGPIODR8R0x508
775GPIO Open Drain Select0x0000.0000RWGPIOODR0x50C
776GPIO Pull-Up Select-RWGPIOPUR0x510
778GPIO Pull-Down Select0x0000.0000RWGPIOPDR0x514
780GPIO Slew Rate Control Select0x0000.0000RWGPIOSLR0x518
781GPIO Digital Enable-RWGPIODEN0x51C
783GPIO Lock0x0000.0001RWGPIOLOCK0x520
784GPIO Commit--GPIOCR0x524
786GPIO Analog Mode Select0x0000.0000RWGPIOAMSEL0x528
787GPIO Port Control-RWGPIOPCTL0x52C
789GPIO ADC Control0x0000.0000RWGPIOADCCTL0x530
790GPIO DMA Control0x0000.0000RWGPIODMACTL0x534
791GPIO Select Interrupt0x0000.0000RWGPIOSI0x538
792GPIO 12-mA Drive Select0x0000.0000RWGPIODR12R0x53C
793GPIO Wake Pin Enable0x0000.0000RWGPIOWAKEPEN0x540
795GPIO Wake Level0x0000.0000RWGPIOWAKELVL0x544
797GPIO Wake Status0x0000.0000ROGPIOWAKESTAT0x548
799GPIO Peripheral Property0x0000.0001ROGPIOPP0xFC0
800GPIO Peripheral Configuration0x0000.0000RWGPIOPC0xFC4
803GPIO Peripheral Identification 40x0000.0000ROGPIOPeriphID40xFD0
757June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
