Register 21: GPIO Analog Mode Select (GPIOAMSEL), offset 0x528
Important: This register is only valid for ports and pins that can be used as ADC AINx inputs.
If any pin is to be used as an ADC input, the appropriate bit in GPIOAMSEL must be
set to disable the analog isolation circuit.
The GPIOAMSEL register controls isolation circuits to the analog side of a unified I/O pad. Because
the GPIOs may be driven by a 3.3-V source and affect analog operation, analog circuitry requires
isolation from the pins when they are not used in their analog function.
Each bit of this register controls the isolation circuitry for the corresponding GPIO signal. For
information on which GPIO pins can be used for ADC functions, refer to Table 26-5 on page 1808.
GPIO Analog Mode Select (GPIOAMSEL)
GPIO Port A (AHB) base: 0x4005.8000
GPIO Port B (AHB) base: 0x4005.9000
GPIO Port C (AHB) base: 0x4005.A000
GPIO Port D (AHB) base: 0x4005.B000
GPIO Port E (AHB) base: 0x4005.C000
GPIO Port F (AHB) base: 0x4005.D000
GPIO Port G (AHB) base: 0x4005.E000
GPIO Port H (AHB) base: 0x4005.F000
GPIO Port J (AHB) base: 0x4006.0000
GPIO Port K (AHB) base: 0x4006.1000
GPIO Port L (AHB) base: 0x4006.2000
GPIO Port M (AHB) base: 0x4006.3000
GPIO Port N (AHB) base: 0x4006.4000
GPIO Port P (AHB) base: 0x4006.5000
GPIO Port Q (AHB) base: 0x4006.6000
Offset 0x528
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
GPIOAMSELreserved
RWRWRWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.00ROreserved31:8
GPIO Analog Mode Select
DescriptionValue
The analog function of the pin is disabled, the isolation is
enabled, and the pin is capable of digital functions as specified
by the other GPIO configuration registers.
0
The analog function of the pin is enabled, the isolation is
disabled, and the pin is capable of analog functions.
1
Note: This register and bits are only valid for GPIO signals that
share analog function through a unified I/O pad.
The reset state of this register is 0 for all signals.
0x00RWGPIOAMSEL7:0
June 18, 2014786
Texas Instruments-Production Data
General-Purpose Input/Outputs (GPIOs)
