Texas Instruments TM4C1294NCPDT User Manual

Register 48: Inter-Integrated Circuit Peripheral Present (PPI2C), offset 0x320
The PPI2C register provides software information regarding the I
2
C modules.
Important: This register should be used to determine which I
2
C modules are implemented on this
microcontroller.
Inter-Integrated Circuit Peripheral Present (PPI2C)
Base 0x400F.E000
Offset 0x320
Type RO, reset 0x0000.03FF
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
P0P1P2P3P4P5P6P7P8P9reserved
ROROROROROROROROROROROROROROROROType
1111111111000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:10
I
2
C Module 9 Present
DescriptionValue
I
2
C module 9 is not present.0
I
2
C module 9 is present.1
0x1ROP99
I
2
C Module 8 Present
DescriptionValue
I
2
C module 8 is not present.0
I
2
C module 8 is present.1
0x1ROP88
I
2
C Module 7 Present
DescriptionValue
I
2
C module 7 is not present.0
I
2
C module 7 is present.1
0x1ROP77
I
2
C Module 6 Present
DescriptionValue
I
2
C module 6 is not present.0
I
2
C module 6 is present.1
0x1ROP66
333June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
