Table 8-6. Flash Register Map
See
page
DescriptionResetTypeNameOffset
Internal Memory Registers (Internal Memory Control Offset)
625Flash Memory Address0x0000.0000RWFMA0x000
626Flash Memory Data0x0000.0000RWFMD0x004
627Flash Memory Control0x0000.0000RWFMC0x008
630Flash Controller Raw Interrupt Status0x0000.0000ROFCRIS0x00C
633Flash Controller Interrupt Mask0x0000.0000RWFCIM0x010
635Flash Controller Masked Interrupt Status and Clear0x0000.0000RW1CFCMISC0x014
638Flash Memory Control 20x0000.0000RWFMC20x020
639Flash Write Buffer Valid0x0000.0000RWFWBVAL0x030
640Flash Program/Erase Key0x0000.FFFFROFLPEKEY0x03C
641Flash Write Buffer n0x0000.0000RWFWBn
0x100 -
0x17C
642Flash Peripheral Properties0xF014.01FFROFLASHPP0xFC0
644SRAM Size0x0000.03FFROSSIZE0xFC4
645Flash Configuration Register0x0000.0000RWFLASHCONF0xFC8
647ROM Third-Party Software0x0000.0000ROROMSWMAP0xFCC
649Flash DMA Address Size0x0000.0000RWFLASHDMASZ0xFD0
650Flash DMA Starting Address0x0000.0000RWFLASHDMAST0xFD4
EEPROM Registers (EEPROM Control Offset)
651EEPROM Size Information0x0060.0600ROEESIZE0x000
652EEPROM Current Block0x0000.0000RWEEBLOCK0x004
653EEPROM Current Offset0x0000.0000RWEEOFFSET0x008
654EEPROM Read-Write-RWEERDWR0x010
655EEPROM Read-Write with Increment-RWEERDWRINC0x014
656EEPROM Done Status0x0000.0000ROEEDONE0x018
658EEPROM Support Control and Status-RWEESUPP0x01C
659EEPROM Unlock-RWEEUNLOCK0x020
660EEPROM Protection0x0000.0000RWEEPROT0x030
662EEPROM Password-RWEEPASS00x034
662EEPROM Password-RWEEPASS10x038
662EEPROM Password-RWEEPASS20x03C
663EEPROM Interrupt0x0000.0000RWEEINT0x040
June 18, 2014622
Texas Instruments-Production Data
Internal Memory
