Register 3: Power-Temp Brown Out Control (PTBOCTL), offset 0x038
This register determines, based on an individual event level, the appropriate next level of action (for
example, NONE, System Control Interrupt, NMI, or reset) when an event occurs.
Power-temperature event actions are directed to the core as a System Control Interrupt or NMI.
When a reset occurs, its behavior is controlled by the Reset Behavior Control (RESBEHAVCTL)
register. If one of the events configured in the PTBOCTL register causes a reset, it is registered as
a BOR interrupt in the Reset Cause (RESC) register.
Note: V
DDA
is the supply voltage to the analog components of the device and V
DD
is the supply
voltage to the digital components of the device.
Power-Temp Brown Out Control (PTBOCTL)
Base 0x400F.E000
Offset 0x038
Type RW, reset 0x0000.0003
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
VDD_UBORreservedVDDA_UBORreserved
RWRWRORORORORORORWRWROROROROROROType
1100000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:10
V
DDA
under BOR Event Action
An event occurs when V
DDA
trips under the V
DDA_BOR0
threshold found
in Table 27-13 on page 1826.
This field determines the action to take on the event.
DescriptionValue
No Action0x0
System control interrupt0x1
NMI0x2
Reset0x3
0RWVDDA_UBOR9:8
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved7:2
