Register 88: PWM Peripheral Properties (PWMPP), offset 0xFC0
The PWMPP register provides information regarding the properties of the PWM module.
PWM Peripheral Properties (PWMPP)
PWM0 base: 0x4002.8000
Offset 0xFC0
Type RO, reset 0x0000.0344
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
GCNTFCNTESYNCEFAULTONEreserved
ROROROROROROROROROROROROROROROROType
0010001011000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0ROreserved31:11
One-Shot Mode
DescriptionValue
One-shot modes are not available.0
One-shot modes are available.1
0x0ROONE10
Extended Fault
DescriptionValue
Extended fault capabilities are not available.0
Extended fault capabilities are available.1
0x1ROEFAULT9
Extended Synchronization
DescriptionValue
Extended synchronization is not available.0
Extended synchronization is available.1
0x1ROESYNC8
Fault Inputs
DescriptionValue
No fault inputs.0x0
1 fault input.0x1
2 fault input.0x2
3 fault input.0x3
4 fault input.0x4
reserved0x5 - 0xF
0x4ROFCNT7:4
1745June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
