Register 93: Universal Asynchronous Receiver/Transmitter Run Mode Clock
Gating Control (RCGCUART), offset 0x618
The RCGCUART register provides software the capability to enable and disable the UART modules
in Run mode. When enabled, a module is provided a clock and accesses to module registers are
allowed. When disabled, the clock is disabled to save power and accesses to module registers
generate a bus fault.
Important: This register should be used to control the clocking for the UART modules.
Universal Asynchronous Receiver/Transmitter Run Mode Clock Gating Control (RCGCUART)
Base 0x400F.E000
Offset 0x618
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
R0R1R2R3R4R5R6R7reserved
RWRWRWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:8
UART Module 7 Run Mode Clock Gating Control
DescriptionValue
UART module 7 is disabled.0
Enable and provide a clock to UART module 7 in Run mode.1
0RWR77
UART Module 6 Run Mode Clock Gating Control
DescriptionValue
UART module 6 is disabled.0
Enable and provide a clock to UART module 6 in Run mode.1
0RWR66
UART Module 5 Run Mode Clock Gating Control
DescriptionValue
UART module 5 is disabled.0
Enable and provide a clock to UART module 5 in Run mode.1
0RWR55
UART Module 4 Run Mode Clock Gating Control
DescriptionValue
UART module 4 is disabled.0
Enable and provide a clock to UART module 4 in Run mode.1
0RWR44
June 18, 2014388
Texas Instruments-Production Data
System Control
