Register 63: LCD Peripheral Present (PPLCD), offset 0x390
The PPLCD register provides software information regarding the LCD module.
Important: This register should be used to determine if an LCD controller is implemented on this
microcontroller.
LCD Peripheral Present (PPLCD)
Base 0x400F.E000
Offset 0x390
Type RO, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
P0reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:1
LCD Module Present
DescriptionValue
LCD module is not present.0
LCD module is present.1
0x0ROP00
349June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
