Texas Instruments TM4C1294NCPDT User Manual

Register 31: ADC Sample Sequence Control 1 (ADCSSCTL1), offset 0x064
Register 32: ADC Sample Sequence Control 2 (ADCSSCTL2), offset 0x084
These registers contain the configuration information for each sample for a sequence executed with
Sample Sequencer 1 or 2. When configuring a sample sequence, the END bit must be set for the
final sample, whether it be after the first sample, fourth sample, or any sample in between. These
registers are 16-bits wide and contain information for four possible samples. See the ADCSSCTL0
register on page 1111 for detailed bit descriptions. The ADCSSCTL1 register configures Sample
Sequencer 1 and the ADCSSCTL2 register configures Sample Sequencer 2.
ADC Sample Sequence Control n (ADCSSCTLn)
ADC0 base: 0x4003.8000
ADC1 base: 0x4003.9000
Offset 0x064
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
D0END0IE0TS0D1END1IE1TS1D2END2IE2TS2D3END3IE3TS3
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000ROreserved31:16
4th Sample Temp Sensor Select
DescriptionValue
The input pin specified by the ADCSSMUXn register is read
during the fourth sample of the sample sequence.
0
The temperature sensor is read during the fourth sample of the
sample sequence.
1
0RWTS315
4th Sample Interrupt Enable
DescriptionValue
The raw interrupt is not asserted to the interrupt controller.0
The raw interrupt signal (INR0 bit) is asserted at the end of the
fourth sample's conversion. If the MASK0 bit in the ADCIM
register is set, the interrupt is promoted to the interrupt controller.
1
It is legal to have multiple samples within a sequence generate interrupts.
0RWIE314
June 18, 20141130
Texas Instruments-Production Data
Analog-to-Digital Converter (ADC)
