Register 73: Hibernation Software Reset (SRHIB), offset 0x514
The SRHIB register provides software the capability to reset the available Hibernation module.
A peripheral is reset by software using a simple two-step process:
1. Software sets a bit (or bits) in the SRHIB register. While the SRHIB bit is 1, the peripheral is
held in reset.
2. Software completes the reset process by clearing the SRHIB bit.
There may be latency from the clearing of the SRHIB bit to when the peripheral is ready for use.
Software should check the corresponding PRHIB bit to verify that the Hibernation Module registers
are ready to be accessed.
Important: This register should be used to reset the Hibernation module.
Hibernation Software Reset (SRHIB)
Base 0x400F.E000
Offset 0x514
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
R0reserved
RWROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:1
Hibernation Module Software Reset
DescriptionValue
Hibernation module is not reset.0
Hibernation module is reset.1
0RWR00
June 18, 2014362
