Register 15: Hibernation Calendar 1 (HIBCAL1), offset 0x314
The Hibernation Calendar 1 (HIBCAL1) register is used when the CALEN bit is set in the
HIBCALCTL register.
Hibernation Calendar 1 (HIBCAL1)
Base 0x400F.C000
Offset 0x314
Type RO, reset 0x0000.0000
16171819202122232425262728293031
YEARreservedDOWreservedVALID
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
DOMreservedMONreserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Valid Calendar Load
The calendar may take several cycles to update as the values roll over.
This bit indicates whether the HIBCAL1 register contents are valid.
DescriptionValue
Register currently updating or initializing0
HIBCAL1 register valid and ready.1
0ROVALID31
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved30:27
Day of Week
This field displays the day of the week in the encodings 0x0 to 0x6. The
application defines which days are assigned to each encoding.
0RODOW26:24
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved23
Year Value
The last two digits of the year are stored in hexadecimal in this field.
Bits 22:16 correspond to hex values from 0x0 to 0x63 (0 to 99 years).
0ROYEAR22:16
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved15:12
Month
This field holds the month value in hexadecimal.
Bits 11:8 correspond to hex values from 0x1 to 0xC (1 to 12 months).
0ROMON11:8
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved7:5
June 18, 2014578
Texas Instruments-Production Data
Hibernation Module
