Register 8: QEI Velocity (QEISPEED), offset 0x01C
This register contains the most recently measured velocity of the quadrature encoder. This value
corresponds to the number of velocity pulses counted in the previous velocity timer period. This
register does not update when the VELEN bit in the QEICTL register is clear.
QEI Velocity (QEISPEED)
QEI0 base: 0x4002.C000
Offset 0x01C
Type RO, reset 0x0000.0000
16171819202122232425262728293031
SPEED
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
SPEED
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Velocity
The measured speed of the quadrature encoder in pulses per period.
0x0000.0000ROSPEED31:0
June 18, 20141764
Texas Instruments-Production Data
Quadrature Encoder Interface (QEI)
