Register 17: UART Peripheral Properties (UARTPP), offset 0xFC0
The UARTPP register provides information regarding the properties of the UART module.
UART Peripheral Properties (UARTPP)
UART0 base: 0x4000.C000
UART1 base: 0x4000.D000
UART2 base: 0x4000.E000
UART3 base: 0x4000.F000
UART4 base: 0x4001.0000
UART5 base: 0x4001.1000
UART6 base: 0x4001.2000
UART7 base: 0x4001.3000
Offset 0xFC0
Type RO, reset 0x0000.000F
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
SCNBMSMSEreserved
ROROROROROROROROROROROROROROROROType
1111000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0ROreserved31:4
Modem Support Extended
DescriptionValue
The UART module does not provide extended support for
modem control.
0
The UART module provides extended support for modem control
including UARTnDTR, UARTnDSR, UARTnDCD, and UARTnRI.
1
0x1ROMSE3
Modem Support
DescriptionValue
The UART module does not provide support for modem control.0
The UART module provides support for modem control including
UARTnRTS and UARTnCTS.
1
0x1ROMS2
9-Bit Support
DescriptionValue
The UART module does not provide support for the transmission
of 9-bit data for RS-485 support.
0
The UART module provides support for the transmission of 9-bit
data for RS-485 support.
1
0x1RONB1
