Register 25: ADC Sample Sequence 0 Operation (ADCSSOP0), offset 0x050
This register determines whether the sample from the given conversion on Sample Sequence 0 is
saved in the Sample Sequence FIFO0 or sent to the digital comparator unit.
ADC Sample Sequence 0 Operation (ADCSSOP0)
ADC0 base: 0x4003.8000
ADC1 base: 0x4003.9000
Offset 0x050
Type RW, reset 0x0000.0000
16171819202122232425262728293031
S4DCOPreservedS5DCOPreservedS6DCOPreservedS7DCOPreserved
RWRORORORWRORORORWRORORORWROROROType
0000000000000000Reset
0123456789101112131415
S0DCOPreservedS1DCOPreservedS2DCOPreservedS3DCOPreserved
RWRORORORWRORORORWRORORORWROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0ROreserved31:29
Sample 7 Digital Comparator Operation
DescriptionValue
The eighth sample is saved in Sample Sequence FIFO0.0
The eighth sample is sent to the digital comparator unit specified
by the S7DCSEL bit in the ADCSSDC0 register, and the value
is not written to the FIFO.
1
0RWS7DCOP28
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0ROreserved27:25
Sample 6 Digital Comparator Operation
Same definition as S7DCOP but used during the seventh sample.
0RWS6DCOP24
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0ROreserved23:21
Sample 5 Digital Comparator Operation
Same definition as S7DCOP but used during the sixth sample.
0RWS5DCOP20
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0ROreserved19:17
Sample 4 Digital Comparator Operation
Same definition as S7DCOP but used during the fifth sample.
0RWS4DCOP16
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0ROreserved15:13
