Texas Instruments TM4C1294NCPDT User Manual

Register 107: 16/32-Bit General-Purpose Timer Sleep Mode Clock Gating
Control (SCGCTIMER), offset 0x704
The SCGCGPT32 register provides software the capability to enable and disable 16/32-bit timer
modules in sleep mode. When enabled, a module is provided a clock. When disabled, the clock is
disabled to save power.
Important: This register should be used to control the clocking for the timer modules.
16/32-Bit General-Purpose Timer Sleep Mode Clock Gating Control (SCGCTIMER)
Base 0x400F.E000
Offset 0x704
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
S0S1S2S3S4S5S6S7reserved
RWRWRWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:8
16/32-Bit General-Purpose Timer 7 Sleep Mode Clock Gating Control
DescriptionValue
16/32-bit general-purpose timer module 7 is disabled in sleep
mode.
0
Enable and provide a clock to 16/32-bit general-purpose timer
module 7 in sleep mode.
1
0RWS77
16/32-Bit General-Purpose Timer 6 Sleep Mode Clock Gating Control
DescriptionValue
16/32-bit general-purpose timer module 6 is disabled in sleep
mode.
0
Enable and provide a clock to 16/32-bit general-purpose timer
module 6 in sleep mode.
1
0RWS66
16/32-Bit General-Purpose Timer 5 Sleep Mode Clock Gating Control
DescriptionValue
16/32-bit general-purpose timer module 5 is disabled in sleep
mode.
0
Enable and provide a clock to 16/32-bit general-purpose timer
module 5 in sleep mode.
1
0RWS55
June 18, 2014404
Texas Instruments-Production Data
