Register 4: GPIO Interrupt Both Edges (GPIOIBE), offset 0x408
The GPIOIBE register allows both edges to cause interrupts. When the corresponding bit in the
GPIO Interrupt Sense (GPIOIS) register (see page 761) is set to detect edges, setting a bit in the
GPIOIBE register configures the corresponding pin to detect both rising and falling edges, regardless
of the corresponding bit in the GPIO Interrupt Event (GPIOIEV) register (see page 763). Clearing
a bit configures the pin to be controlled by the GPIOIEV register. All bits are cleared by a reset.
Note: To prevent false interrupts, the following steps should be taken when re-configuring GPIO
edge and interrupt sense registers:
1. Mask the corresponding port by clearing the IME field in the GPIOIM register.
2. Configure the IS field in the GPIOIS register and the IBE field in the GPIOIBE register.
3. Clear the GPIORIS register.
4. Unmask the port by setting the IME field in the GPIOIM register.
GPIO Interrupt Both Edges (GPIOIBE)
GPIO Port A (AHB) base: 0x4005.8000
GPIO Port B (AHB) base: 0x4005.9000
GPIO Port C (AHB) base: 0x4005.A000
GPIO Port D (AHB) base: 0x4005.B000
GPIO Port E (AHB) base: 0x4005.C000
GPIO Port F (AHB) base: 0x4005.D000
GPIO Port G (AHB) base: 0x4005.E000
GPIO Port H (AHB) base: 0x4005.F000
GPIO Port J (AHB) base: 0x4006.0000
GPIO Port K (AHB) base: 0x4006.1000
GPIO Port L (AHB) base: 0x4006.2000
GPIO Port M (AHB) base: 0x4006.3000
GPIO Port N (AHB) base: 0x4006.4000
GPIO Port P (AHB) base: 0x4006.5000
GPIO Port Q (AHB) base: 0x4006.6000
Offset 0x408
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
IBEreserved
RWRWRWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.00ROreserved31:8
GPIO Interrupt Both Edges
DescriptionValue
Interrupt generation is controlled by the GPIO Interrupt Event
(GPIOIEV) register (see page 763).
0
Both edges on the corresponding pin trigger an interrupt.1
0x00RWIBE7:0
June 18, 2014762
Texas Instruments-Production Data
General-Purpose Input/Outputs (GPIOs)
