Register 64: ADC Peripheral Properties (ADCPP), offset 0xFC0
The ADCPP register provides information regarding the properties of the ADC module.
ADC Peripheral Properties (ADCPP)
ADC0 base: 0x4003.8000
ADC1 base: 0x4003.9000
Offset 0xFC0
Type RO, reset 0x01B0.2147
16171819202122232425262728293031
TYPERSLTSAPSHTreserved
ROROROROROROROROROROROROROROROROType
0000110110000000Reset
0123456789101112131415
MCRCHDC
ROROROROROROROROROROROROROROROROType
1110001010000100Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x00ROreserved31:25
Application-Programmable Sample-and-Hold Time
This bit indicates the ADC has the capability of allowing the application
to adjust the sample and hold window period.
0x1ROAPSHT24
Temperature Sensor
DescriptionValue
The ADC module does not have a temperature sensor.0
The ADC module has a temperature sensor.1
This field provides the similar information as the legacy DC1 register
TEMPSNS bit.
0x1ROTS23
Resolution
This field specifies the maximum number of binary bits used to represent
the converted sample. The field is encoded as a binary value, in the
range of 0 to 32 bits.
0xCRORSL22:18
ADC Architecture
DescriptionValue
SAR0x0
Reserved0x1 - 0x3
0x0ROTYPE17:16
Digital Comparator Count
This field specifies the number of ADC digital comparators available to
the converter. The field is encoded as a binary value, in the range of 0
to 63.
This field provides similar information to the legacy DC9 register
ADCnDCn bits.
0x8RODC15:10
1157June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
