Table 13-11. Timers Register Map (continued)
See
page
DescriptionResetTypeNameOffset
996GPTM Raw Interrupt Status0x0000.0000ROGPTMRIS0x01C
999GPTM Masked Interrupt Status0x0000.0000ROGPTMMIS0x020
1002GPTM Interrupt Clear0x0000.0000W1CGPTMICR0x024
1004GPTM Timer A Interval Load0xFFFF.FFFFRWGPTMTAILR0x028
1005GPTM Timer B Interval Load0x0000.FFFFRWGPTMTBILR0x02C
1006GPTM Timer A Match0xFFFF.FFFFRWGPTMTAMATCHR0x030
1007GPTM Timer B Match0x0000.FFFFRWGPTMTBMATCHR0x034
1008GPTM Timer A Prescale0x0000.0000RWGPTMTAPR0x038
1009GPTM Timer B Prescale0x0000.0000RWGPTMTBPR0x03C
1010GPTM TimerA Prescale Match0x0000.0000RWGPTMTAPMR0x040
1011GPTM TimerB Prescale Match0x0000.0000RWGPTMTBPMR0x044
1012GPTM Timer A0xFFFF.FFFFROGPTMTAR0x048
1013GPTM Timer B0x0000.FFFFROGPTMTBR0x04C
1014GPTM Timer A Value0xFFFF.FFFFRWGPTMTAV0x050
1015GPTM Timer B Value0x0000.FFFFRWGPTMTBV0x054
1016GPTM RTC Predivide0x0000.7FFFROGPTMRTCPD0x058
1017GPTM Timer A Prescale Snapshot0x0000.0000ROGPTMTAPS0x05C
1018GPTM Timer B Prescale Snapshot0x0000.0000ROGPTMTBPS0x060
1019GPTM DMA Event0x0000.0000RWGPTMDMAEV0x06C
1022GPTM ADC Event0x0000.0000RWGPTMADCEV0x070
1025GPTM Peripheral Properties0x0000.0070ROGPTMPP0xFC0
1027GPTM Clock Configuration0x0000.0000RWGPTMCC0xFC8
13.6 Register Descriptions
The remainder of this section lists and describes the GPTM registers, in numerical order by address
offset.
975June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
