Register 12: GPTM Timer A Match (GPTMTAMATCHR), offset 0x030
This register is loaded with a match value. Interrupts can be generated when the timer value is equal
to the value in this register in one-shot or periodic mode.
In Edge-Count mode, this register along with GPTMTAILR, determines how many edge events are
counted. The total number of edge events counted is equal to the value in GPTMTAILR minus this
value. Note that in edge-count mode, when executing an up-count, the value of GPTMTnPR and
GPTMTnILR must be greater than the value of GPTMTnPMR and GPTMTnMATCHR.
In PWM mode, this value along with GPTMTAILR, determines the duty cycle of the output PWM
signal.
When a 16/32-bit GPTM is configured to one of the 32-bit modes, GPTMTAMATCHR appears as
a 32-bit register (the upper 16-bits correspond to the contents of the GPTM Timer B Match
(GPTMTBMATCHR) register). In a 16-bit mode, the upper 16 bits of this register read as 0s and
have no effect on the state of GPTMTBMATCHR.
GPTM Timer A Match (GPTMTAMATCHR)
16/32-bit Timer 0 base: 0x4003.0000
16/32-bit Timer 1 base: 0x4003.1000
16/32-bit Timer 2 base: 0x4003.2000
16/32-bit Timer 3 base: 0x4003.3000
16/32-bit Timer 4 base: 0x4003.4000
16/32-bit Timer 5 base: 0x4003.5000
16/32-bit Timer 6 base: 0x400E.0000
16/32-bit Timer 7 base: 0x400E.1000
Offset 0x030
Type RW, reset 0xFFFF.FFFF
16171819202122232425262728293031
TAMR
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
1111111111111111Reset
0123456789101112131415
TAMR
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
1111111111111111Reset
DescriptionResetTypeNameBit/Field
GPTM Timer A Match Register
This value is compared to the GPTMTAR register to determine match
events.
0xFFFF.FFFFRWTAMR31:0
June 18, 20141006
Texas Instruments-Production Data
General-Purpose Timers
