Register 69: 16/32-Bit General-Purpose Timer Software Reset (SRTIMER),
offset 0x504
The SRTIMER register provides software the capability to reset the available 16/32-bit timer modules.
A peripheral is reset by software using a simple two-step process:
1. Software sets a bit (or bits) in the SRTIMER register. While the SRTIMER bit is 1, the peripheral
is held in reset.
2. Software completes the reset process by clearing the SRTIMER bit.
There may be latency from the clearing of the SRTIMER bit to when the peripheral is ready for use.
Software should check the corresponding PRTIMER bit to verify that the Timer Module registers
are ready to be accessed.
Important: This register should be used to reset the timer modules.
16/32-Bit General-Purpose Timer Software Reset (SRTIMER)
Base 0x400F.E000
Offset 0x504
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
R0R1R2R3R4R5R6R7reserved
RWRWRWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:8
16/32-Bit General-Purpose Timer 7 Software Reset
DescriptionValue
16/32-bit general-purpose timer module 7 is not reset.0
16/32-bit general-purpose timer module 7 is reset.1
0RWR77
16/32-Bit General-Purpose Timer 6 Software Reset
DescriptionValue
16/32-bit general-purpose timer module 6 is not reset.0
16/32-bit general-purpose timer module 6 is reset.1
0RWR66
355June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
