Register 27: GPTM Peripheral Properties (GPTMPP), offset 0xFC0
The GPTMPP register provides information regarding the properties of the General-Purpose Timer
module.
GPTM Peripheral Properties (GPTMPP)
16/32-bit Timer 0 base: 0x4003.0000
16/32-bit Timer 1 base: 0x4003.1000
16/32-bit Timer 2 base: 0x4003.2000
16/32-bit Timer 3 base: 0x4003.3000
16/32-bit Timer 4 base: 0x4003.4000
16/32-bit Timer 5 base: 0x4003.5000
16/32-bit Timer 6 base: 0x400E.0000
16/32-bit Timer 7 base: 0x400E.1000
Offset 0xFC0
Type RO, reset 0x0000.0070
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
SIZECHAINSYNCCNTALTCLKreserved
ROROROROROROROROROROROROROROROROType
0000111000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:7
Alternate Clock Source
DescriptionValue
The alternate clock source (ALTCLK) is not available to the
Timer module.
0
The alternate clock source (ALTCLK) is available to the Timer
module.
1
0x1ROALTCLK6
Synchronize Start
DescriptionValue
Timer is not capable of synchronizing the counter value with
other GPTimers.
0
Timer is capable of synchronizing the counter value with other
Timers.
1
0x1ROSYNCCNT5
Chain with Other Timers
DescriptionValue
Timer is not capable of chaining with the previously numbered
Timer.
0
Timer is capable of chaining with the previously numbered
Timer.
1
Note that although this bit is set for Timer 0A, this timer cannot chain
because there is not a previously numbered Timer.
0x1ROCHAIN4
