Register 3: I
2
C Master Data (I2CMDR), offset 0x008
Important: This register is read-sensitive. See the register description for details.
This register contains the data to be transmitted when in the Master Transmit state and the data
received when in the Master Receive state. If the BURST bit is enabled in the I2CMCS register, then
the I2CFIFODATA register is used for the current data transmit or receive value and this register
is ignored.
I2C Master Data (I2CMDR)
I2C 0 base: 0x4002.0000
I2C 1 base: 0x4002.1000
I2C 2 base: 0x4002.2000
I2C 3 base: 0x4002.3000
I2C 4 base: 0x400C.0000
I2C 5 base: 0x400C.1000
I2C 6 base: 0x400C.2000
I2C 7 base: 0x400C.3000
I2C 8 base: 0x400B.8000
I2C 9 base: 0x400B.9000
Offset 0x008
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
DATAreserved
RWRWRWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.00ROreserved31:8
This byte contains the data transferred during a transaction.0x00RWDATA7:0
June 18, 20141312
Texas Instruments-Production Data
Inter-Integrated Circuit (I
2
C) Interface
