Texas Instruments TM4C1294NCPDT User Manual

Register 68: PWM0 Fault Source 1 (PWM0FLTSRC1), offset 0x078
Register 69: PWM1 Fault Source 1 (PWM1FLTSRC1), offset 0x0B8
Register 70: PWM2 Fault Source 1 (PWM2FLTSRC1), offset 0x0F8
Register 71: PWM3 Fault Source 1 (PWM3FLTSRC1), offset 0x138
This register specifies which digital comparator triggers from the ADC are used to generate a fault
condition. Each bit in the following register indicates whether the corresponding digital comparator
trigger is included in the fault condition. All enabled digital comparator triggers are ORed together
to form the PWMnFLTSRC1 portion of the fault condition. The PWMnFLTSRC1 fault condition is
then ORed with the PWMnFLTSRC0 fault condition to generate the final fault condition for the PWM
generator.
If the FLTSRC bit in the PWMnCTL register (see page 1708) is clear, only the PWM Fault0 pin affects
the fault condition generated. Otherwise, sources defined in PWMnFLTSRC0 and PWMnFLTSRC1
affect the fault condition generated.
PWMn Fault Source 1 (PWMnFLTSRC1)
PWM0 base: 0x4002.8000
Offset 0x078
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
DCMP0DCMP1DCMP2DCMP3DCMP4DCMP5DCMP6DCMP7reserved
RWRWRWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.00ROreserved31:8
Digital Comparator 7
DescriptionValue
The trigger from digital comparator 7 is suppressed and cannot
generate a fault condition.
0
The trigger from digital comparator 7 is ORed with all other fault
condition generation inputs (Faultn signals and digital
comparators).
1
Note: The FLTSRC bit in the PWMnCTL register must be set for this
bit to affect fault condition generation.
0RWDCMP77
1735June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
