Table 23-2. PWM Register Map (continued)
See
page
DescriptionResetTypeNameOffset
1739PWM1 Fault Pin Logic Sense0x0000.0000RWPWM1FLTSEN0x880
1740PWM1 Fault Status 00x0000.0000-PWM1FLTSTAT00x884
1742PWM1 Fault Status 10x0000.0000-PWM1FLTSTAT10x888
1739PWM2 Fault Pin Logic Sense0x0000.0000RWPWM2FLTSEN0x900
1740PWM2 Fault Status 00x0000.0000-PWM2FLTSTAT00x904
1742PWM2 Fault Status 10x0000.0000-PWM2FLTSTAT10x908
1739PWM3 Fault Pin Logic Sense0x0000.0000RWPWM3FLTSEN0x980
1740PWM3 Fault Status 00x0000.0000-PWM3FLTSTAT00x984
1742PWM3 Fault Status 10x0000.0000-PWM3FLTSTAT10x988
1745PWM Peripheral Properties0x0000.0344ROPWMPP0xFC0
1747PWM Clock Configuration0x0000.0005RWPWMCC0xFC8
23.6 Register Descriptions
The remainder of this section lists and describes the PWM registers, in numerical order by address
offset.
June 18, 20141682
Texas Instruments-Production Data
Pulse Width Modulator (PWM)
