Texas Instruments TM4C1294NCPDT User Manual

Register 8: Analog Comparator Control 0 (ACCTL0), offset 0x024
Register 9: Analog Comparator Control 1 (ACCTL1), offset 0x044
Register 10: Analog Comparator Control 2 (ACCTL2), offset 0x064
These registers configure the comparator's input and output.
Analog Comparator Control n (ACCTLn)
Base 0x4003.C000
Offset 0x024
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
reservedCINVISENISLVALTSENTSLVALreservedASRCPTOENreserved
RORWRWRWRWRWRWRWRORWRWRWROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.0ROreserved31:12
Trigger Output Enable
DescriptionValue
ADC events are suppressed and not sent to the ADC.0
ADC events are sent to the ADC.1
0RWTOEN11
Analog Source Positive
The ASRCP field specifies the source of input voltage to the VIN+ terminal
of the comparator. The encodings for this field are as follows:
DescriptionValue
Pin value of Cn+0x0
Pin value of C0+0x1
Internal voltage reference (V
IREF
)0x2
Reserved0x3
0x0RWASRCP10:9
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved8
Trigger Sense Level Value
DescriptionValue
An ADC event is generated if the comparator output is Low.0
An ADC event is generated if the comparator output is High.1
0RWTSLVAL7
1665June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
