Register 7: Watchdog Test (WDTTEST), offset 0x418
This register provides user-enabled stalling when the microcontroller asserts the CPU halt flag
during debug.
Watchdog Test (WDTTEST)
WDT0 base: 0x4000.0000
WDT1 base: 0x4000.1000
Offset 0x418
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
reservedSTALLreserved
RORORORORORORORORWROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.00ROreserved31:9
Watchdog Stall Enable
DescriptionValue
The watchdog timer continues counting if the microcontroller is
stopped with a debugger.
0
If the microcontroller is stopped with a debugger, the watchdog
timer stops counting. Once the microcontroller is restarted, the
watchdog timer resumes counting.
1
0RWSTALL8
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x00ROreserved7:0
1039June 18, 2014
Texas Instruments-Production Data
