Texas Instruments TM4C1294NCPDT User Manual

Register 8: Interrupt 0-31 Clear Enable (DIS0), offset 0x180
Register 9: Interrupt 32-63 Clear Enable (DIS1), offset 0x184
Register 10: Interrupt 64-95 Clear Enable (DIS2), offset 0x188
Register 11: Interrupt 96-113 Clear Enable (DIS3), offset 0x18C
Note: This register can only be accessed from privileged mode.
The DISn registers disable interrupts. Bit 0 of DIS0 corresponds to Interrupt 0; bit 31 corresponds
to Interrupt 31. Bit 0 of DIS1 corresponds to Interrupt 32; bit 31 corresponds to Interrupt 63. Bit 0 of
DIS2 corresponds to Interrupt 64; bit 31 corresponds to Interrupt 95. Bit 0 of DIS3 corresponds to
Interrupt 96; .
See Table 2-9 on page 116 for interrupt assignments.
Interrupt 0-31 Clear Enable (DIS0)
Base 0xE000.E000
Offset 0x180
Type RW, reset 0x0000.0000
16171819202122232425262728293031
INT
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
0123456789101112131415
INT
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Interrupt Disable
DescriptionValue
On a read, indicates the interrupt is disabled.
On a write, no effect.
0
On a read, indicates the interrupt is enabled.
On a write, clears the corresponding INT[n] bit in the EN0
register, disabling interrupt [n].
1
0x0000.0000RWINT31:0
155June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
